    CE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd Display

    Ask Lasest Price
    Brand Name : SUNMEG
    Model Number : LX15431LX-31
    Certification : CE,FCC,ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 60K pcs/month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    CE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd Display


    Smart Home, Payment Terminals, Telecommunication Devices, Security

    System Equipments, Automobile Electronics, Medical Equipments,

    Household Electrical appliances ,has the capability to produce low power

    consumption, widely viewing angle and widely temperature range of LCD

    modules. Our machines imported from Taiwan and Japan.We have

    an efficient procurement, production and quality control system, which

    ensure a rapid delivery with high-quality products and competitive price.


    Product name:LCD TFT Displays
    Resolution:128*128
    Outline Dimension:31.52*33.72*1.73mm
    LCD Active Area(mm):25.5*26.5mm
    Interface:SPI 4-line
    Viewing Angle:free viewing angle
    Driving IC:ST7789V2
    Display Mode:Normally White
    Technology Type:a-Si TFT active matrix
    Surface treatment:Anti-Glare
    Operating Temperature:-20 to +70ºC
    Storage Temperature:-30 to +80ºC
    Brightness:350Cd/m2
    OEMSupport

    CE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd DisplayCE 1.54Inch Square Tft Display / Spi Interface 128x128 Lcd Display


    FAQ:

    Q1. Do you have MOQ requirement?
    A: Yes, it depends on different sizes of products. Please refer to our sales, thanks.


    Q2. How do I work with you on Customized products?
    A: Firstly please provide us the description of your special requirements, any Drawing or Specification---Our engineers will work out the compatible solution and also mould cost (if any)---We provide Drawing and Specification for Approval---We provide samples for approval after reliability test and aging test---We make modification if necessary---We do small quantity of trial order (if required)---We do mass production.


    Q3. Can I have my own silk screen Logo, Part Number or small label ?
    A: Yes, Definitely. It may requires MOQ, please refer to our sales, thanks.


    Q4.How long is the warranty and what is your after-sales service ?
    A: Usually 12 Months.

    If there is any defect within 12months from receiving products, please contact our sales, we will respond within 24hours. If we require any product to be returned to us, the shipping cost will be fully paid by us.


    Q5. Do you have any shipping account and can you quote favorable shipping cost ?

    A: Yes, we have been working with DHL, Fedex more than 11 years, our shipping accounts were granted discount as much as 85% off . Please feel free to ask our sales no matter it is sample or formal order shipment.


    Q6. Can I have a sample order of before formal order?
    A: Yes, sample order is always welcome for new projects or replacement of running projects. We have stock of many standard models of TFT LCD modules and Touch screens from 0.96inch to 13.3inch , which means delivery is able to be made the same day as order.
