Our LCD module products ranged from TN, HTN, STN, FSTN with
various types of assembly such as COB, COG, TAB and many
customized segment LCD modules.Products widely used in Video,
Car instrument, Vending machine, Telephones, Electronic
meters, Door-phone, all kinds of terminal equipment .etc
It is a Transmissive type color active matrix liquid crystal
display (LCD).
It is composed of a TFT LCD panel, driver IC, FPC and backlight
unit.
Backlight with different brightness is customized according to your
request.
Capacitive & Resistive touch panel/ Demo board is available for
your option.
It's Standard and Ready-made TFT LCD Module.
Experienced Team for Your Custom Solution.
| Product name: | TFT LCD Module |
| Resolution: | 800x480 |
| Interface: | RGB 40Pin |
| Brightness: | 500cd/m2 |
| Active Area: | 154.08mm x 85.92mm |
| Outline Dimension: | 164.9mm(W)x100mm(H)x5.32mm(T) |
| Touch Panel: | RTP/CTP Optional |
| Operating Temperature: | -20°C + 70°C |
| Storage Temperature: | -30°C +80°C |
| Warranty | 1 year |
Packing and Delivery
1). Payment Terms: T/T
2). Shipping : Prompt delivery by UPS, EMS, DHL, TNT, FedEx, or by
air.
3). Delivery time: 3-7 days for goods in stock, 3-4 weeks for mass
production goods.
4). Packaging Details: Packed in anti-static bags with foam box to
ensure safety in transportation.
5). Delivery Details: 1 to 30 days. The delivery fee is up to the
weight and volume of the products.
FAQ:
Q: Is the product in stock? How long production cycle?
A: Some products are in stock, Small batch production for 1-2
weeks,Mass production for 3-4 weeks.
Q: How long is the product warranty and service?
A: The product is valid for 1 year and is a lifetime technical
support service.
Q: Can you customize the product? what do you need?
A: We can customize as needed, and the quantity has a minimum order
quantity requirement.
Q: Can you provide drawings and related procedures?
A: We can provide drawings and procedures for customers to confirm.
Q: Can the LCD module be Export directly?
A: The products are through the relevant certification, it can be
exported.
Q: Are you a trader or a factory?
A: We are manufacturers, have production trademark and production
workers.
